Yanmar VIO80-1A User operation and maintenance manual/Руководство пользователя по эксплуатации и техническому обслуживанию Yanmar VIO80-1A. - купить книгу в интернет-магазине CentrMag по лучшим ценам! (00-01113360)

Описание Отзывы

Развернуть ▼

Издание на английском языке
This User and Maintenance Manual has been designed to provide you with important information and the suggestions you need for safe and effective use of the machine.Read the manual before you use the machine to familiarise yourself with the operation, verification and maintenance procedures and instructions.A serious accident may be caused if you do not respect the precautions contained in this user manual or use any procedures that are not recommended.

Contents
A Description and illustration of the machine
1 Applications and regulations
1.1 Applications
1.2 Warranty
1.3 Driving permits
1.4 Lifting.
2 Identification plates
2.1 Machine serial number plate
2.2 Engine serial number plate
2.3 EPA information plate
2.4 Spare parts order and intervention request
3 Warning labels
3.1 Location of the warning adhesive labels
3.2 Explanation of the warning adhesive labels
4 Identification of important parts
4.1 General view of the machine
4.2 Commands and switches
5 Description of the driving position
5.1 Operator display station
5.1.1 Indicator lights
5.1.2 Diesel gauge
5.1.3 Cooling fluid temperature indicator
5.1.4 Time counter
5.1.5 Displaying the fuel consumption
5.1.6 Navigation keys
5.1.7 Information and error icons
5.2 Switches
5.2.1 Start key
5.2.2 Headlight switch
5.2.3 Horn?
5.2.4 Windscreen wiper switch and windscreen wiper
5.2.5 Engine rate setting
5.2.6 Side movement switch
5.2.7 Engine slow down switch
5.2.8 Eco mode switch
5.2.9 Engine stop switch
5.2.10 Interior lighting switch
5.2.11 Manual regeneration
5.3 Joysticks and pedals
5.3.1 Locking lever
5.3.2 Right command lever
5.3.3 3rd hydraulic circuit control (P.T.O. 1)
5.3.4 Left command lever
5.3.5 4th hydraulic circuit control (P.T.O. 2)
5.3.6 Travel levers and pedals
5.3.7 Blade lever
5.3.8 Protection of pedals
5.3.9 Boom rotation pedal
5.4 Power socket
5.5 Driver's seat
5.6 Location for the tools and user manual
5.6.1 Toolkit
5.6.2 User manual
5.7 Fuses
5.7.1 Fusebox
5.8 Cabin
5.8.1 Cab side door
5.8.2 Upper windscreen
5.8.3 Lower windscreen
5.8.4 Right hand cab window
5.9 Headlights
6 Operation of the air conditioning
7 Covers
7.1 Bonnet
7.2 Cover B
7.3 Cover R
8 Using the electric fuel filling pump
9 Options
9.1 Long arm.
9.2 Additional counterweights
9.3 Lifting Kit
9.3.1 Lifting ring
9.3.2 Safety valves
9.3.3 Overload box
9.3.4 Lifting Tables
9.4 FOPS 2 protection grill for demolition work
9.5 Cab headlight
9.6 Plug-in flashing light
9.7 Keypad immobilizer
9.8 Immobilizer with coded key
9.9 Anti-starter with key
9.10 Fleet management system
9.11 SMART-ASSIST
9.12 Radio
9.13 Quick hitch
9.14 Centralized greasing system
9.15 Mechanical quick hitch
9.15.1 Mechanical quick hitch ARDEN EQUIPMENT
9.15.2 Mechanical quick hitch RETROMATIC MORIN
9.15.3 Mechanical quick hitch CSERI
9.16 Quick hydraulic hitch CSERI
9.16.1 Dismantling the accessory
9.16.2 Mounting the accessory
B Operating instructions
1 Basic precautions
1.1 Comply with your workplace's safety ruiles
1.2 Put the safety mechanisms in place
1.3 Wear suitable clothing and protective equipment
1.4 Do not drive under the influence of alcohol, drugs or medication
1.5 Provide adequate ventilation when working in an enclosed space
1.6 Protect plants from hot air and exhaust fumes
1.7 Keep fuel and oil away from sparks
1.8 Avoid removing the caps when the temperatures are high
1.9 Avoid crush injuries due to accessories
1.10 Have an extinguisher and a first aid kit
1.11 Avoid any unauthorised modifications
1.12 Precautions for optional parts and tools
1.13 Warning concerning the cab windows
1.14 Cabin's emergency exit
2 Usage precautions
2.1 Precautions before starting the engine
2.1.1 Make sure that your workplace is safe
2.1.2 Clean the machine
2.1.3 Check the safety structures
2.1.4 Check the position of the blade
2.1.5 Accessing the machine
2.1.6 Fasten your safety belt and adjust the rearview mirror(s)
2.2 Movement precautions
2.2.1 Machine's Danger Zone
2.2.2 Movement and accessories
2.2.3 Driving the machine on a slope
2.3 Working precautions
2.3.1 Precautions for using the equipment
2.3.2 Dangerous tasks
2.3.3 Working near electricity lines
2.3.4 Working near obstacles
2.3.5 Emergency stop and securing the machine
2.3.6 Working on a slope
2.3.7 Working in an area covered with snow
2.3.8 Working on unstable ground
2.3.9 Working in a submerged area
2.3.10 Working in a muddy area
2.3.11 Working in an area with reduced visibility
2.4 Parking precautions
2.5 Precautions for the accessories
2.6 Precautions for using optional accessories
2.7 Precautions for the battery
3 Precautions for the engine
4 Checks before starting the machine
4.1 Overall visual inspection
4.2 Checking and topping up the level of cooling fluid
4.3 Checking and topping up the engine oil level
4.4 Checking and topping up the fuel level
4.5 Checking and topping up the hydraulic oil level
5 Checks after start-up
6 Checks after use
7 operator LCD display station interfaces
7.1 Indication of functions
7.2 User Interface
7.3 Maintenance interface
7.4 Machine usage management interface
7.5 Configuration interface
8 Using the machine in cold weather
8.1 Preparation for use in cold weather
8.2 Starting in cold weather
8.3 Precautions after use
8.4 When cold weather is over
9 Rubber tracks
9.1 Correct use of rubber tracks
9.2 Rubber track warranty
9.3 Precautions for using rubber tracks
9.4 Track maintenance
9.5 Track replacement
10 Handling the bucket
10.1 Machine stability when using with a bucket or an accessory
10.2 Compatible accessories
10.3 Operation of the retro bucket
10.4 Digging trenches
10.5 Loading
11 Handling of accessories
11.1 Hydraulic hammer SOCOMEC
12 Accessory change by direct coupling
12.1 Dismantling the accessory
12.2 Mounting the accessory
12.2.1 Loading bucket
13 Load lifting
14 Implementing the 3rd hydraulic circuit
14.1 Description
14.1.1 3rd circuit selector
14.2 Mounting the accessory
14.3 Precautions for using the accessory
15 Using the particle filter
15.1 Auto-regeneration
15.2 Assisted regeneration
15.3 Launching the regeneration
15.4 Manual regeneration of the particulate filter
16 Transporting the machine
16.1 Loading/unloading the machine
16.1.1 Precautions for loading/unloading the machine
16.1.2 Procedure
16.2 Immobilising the machine on the truck
16.3 Tying down the machine
16.4 Slinging the machine
17 Detecting anomalies
17.1 Phenomena that do not constitute faults
17.2 Detecting anomalies
17.2.1 Engine
17.2.2 Electrical equipment
17.2.3 Machine structure
18 If the battery is discharged
18.1 Precautions for connecting and disconnecting the starter cables
18.2 Connecting the starter cables
18.3 Starting the engine
18.4 Disconnecting the starter cables
18.5 Charging the battery
19 Towing the machine
C Periodic maintenance programme
1 Periodic inspections and upkeeps
2 Maintenance precautions
2.1 Precautions before maintenance
2.1.1 Removing the residual pressure
2.1.2 Place a warning label
2.1.3 Establish a safety perimeter
2.1.4 Keep the machine clean
2.2 Precautions during maintenance
2.2.1 Oil and grease
2.2.2 Tools
2.2.3 Parts
2.2.4 Dismantling the accessory
2.2.5 Working under the machine
2.2.6 Lighting
2.2.7 Battery
2.2.8 Hoses
2.2.9 Radiator ventilator
2.2.10 Soldering
2.2.11 Waste processing
3 Recommended greases and fluids
4 First maintenance
4.1 After the first 50 hours of service
5 List of periodic inspections and maintenance operations.
6 Maintenance by the operator
6.1 Daily maintenance
6.1.1 Checking the machine before use
6.1.2 Checks after using the machine
6.1.3 Checking the commands
6.1.4 Checking the seat
6.1.5 Greasing points
6.1.6 Using the centralized greasing system
6.1.7 Cleaning the separator/decanter
6.1.8 Purging the fuel tank
6.1.9 Checking the hydraulic hoses
6.1.10 Visual inspection of the fuel hoses
6.2 Maintenance every 50 hours
6.2.1 Greasing the pin and rotation crown
6.3 Maintenance every 15 days
6.3.1 Checking the air conditioning/heating system
6.4 Non periodic maintenance
6.4.1 Fuse replacement
6.4.2 Replacing a bulb
6.4.3 Top up the windscreen washer fluid.
6.4.4 Replacing the windscreen wiper
6.5 Rubber track maintenance
6.5.1 Checking the condition of the tracks
6.5.2 Track replacement
6.5.3 Tension check
6.5.4 Increasing the tension
6.5.5 Releasing the tension
6.6 Steel track maintenance
6.6.1 Checking the condition of the tracks
6.6.2 Track replacement
6.6.3 Tension check
6.6.4 Increasing the tension
6.6.5 Releasing the tension
7 Maintenance by the dealer
7.1 Maintenance of the particle filter
D Conservation and storage
1 Conservation
2 Storage
3 Recommissioning
E Technical data
1 Specifications
2 Working dimensions
3 Noise emitted by the machine
4 Vibrations emitted by the machine
F Lifting capacities
1 Lifting ViO80-1A
2 Lifting ViO80-1A With rear counterweight
Appendices
A List of error codes displayed on the operator display station
B Control sheets to be photocopied
C Notes
D Lashing record
Index
